Ref. Number Port Description
7 HDCI input for Polycom cameras
8 HDMI input for sharing content (for example, from a laptop)
9 HDMI output for the primary monitor
10 HDMI output for the secondary monitor
11 Primary LAN connection for the system
12 Link-local network (LLN) connections for IP-based peripheral devices
13 Power
Related Links
HDMI Connections on page 76
Related Links
Specify the Primary and Fence Microphones on page 72
Related Links
LED Status Indicators for the System LAN Ports
on page 112
LED Status Indicators for the G7500 System
Use the LED on the front right corner of the codec to get information on the state of your G7500 system.
Figure 2: G7500 System LED Location
G7500 System LED Status Indicators
Indicator Status
Blinking white Powering on
Setting Up the System
Polycom, Inc. 11
