PCX SMS AND PCX 256 SYSTEM MANUAL
RINS871-3 Page: 151
Type Active Restore
procedure completed
0035
Follow Input*
See page: 81.
When input triggers Dependant upon programming
0036 Shunt Fault* See Shunt Inputs - Page: 55
0037 Reset 1 (Viper Reset)
At code entry to arm After 3 seconds
At code entry to arm When disarmed
0038
Reset 2 (Viper
Arm/Disarm)
Re-triggers whenever an additional partition is armed
0039 PIR Latch 1
When armed (and in Walk
Test)
At alarm, or when disarmed
0040 PIR Latch 2
This is the inverse polarity to PIR Latch 1
0041 Mains Good
Output showing the mains is healthy
0042 Detr Indn Enable*
This output activates during walk test and also when a code is
entered to view indications – staying activated for the time for
which the indications are viewed.
0043 Follow Test
New output for alternative bell test by activating SAB
0044 Off During Test
New output for alternative bell test by activating SAB
0051 Telecom Line Fault
When Line Fault signalled by
communicator
When fault clears
0052 AC Fail
After pre-set time without
mains power
On restoration of mains
0053 Battery Faults
When battery disconnected or
load fail detected
At next valid code entry
0054 Low Volts
At fault When fault clears
0055 Global Fault 1
Activates if fault occurs only
when system is armed (Faults:
Modem, Battery, Fuse, Line,
Mains)
When all faults cleared
0056 Global Fault 2
Activates if fault occurs at any
time (Faults: Modem, Battery,
Fuse, Line, Mains)
When all faults cleared
0057 German Relay*
0058 Guard Code Used
When ‘guard’ code accepted After 60 seconds
0059 Engineer Access
When entering Engineer Mode When leaving Engineer Mode
0060 Initialise Digi
At power up Live for 45 seconds only
0063 Test ATE/GSM*
Test signalling through
PSTN and GSM. Activates
when a test call is
sent.(used for specific
GSMs)
When test completed
0064 Test ATS
Test signalling through
PSTN and GSM. Activates
when a test call is sent.
When test completed
0066 ATE not used
Makes the ATE pin 5V.
A repeating block of output types should be noted:
0202 Hold Up A
As 0002 for Partition A / Arm Level A events only
0203 Intruder A
As 0003 for Partition A / Arm Level A events only
0204 Final Arm A
As 0004 for Partition A / Arm Level A events only
0207 Tamper A
As 0007 for Partition A / Arm Level A events only
0208 Duress A
As 0008 for Partition A / Arm Level A events only
0209 HU Device A
As 0009 for Partition A / Arm Level A events only
0213 Secure Intruder A
As 0013 for Partition A / Arm Level A events only
0214 Bell A
As 0014 for Partition A / Arm Level A events only
0216 Strobe A
As 0016 for Partition A / Arm Level A events only
0217 Omit At Rearm A
As 0017 for Partition A / Arm Level A events only
