122 A-Series display - User reference manual
To set engine and tachometer values
1. Press and hold the PAGE/MENU button and select Panel Setup
Menu.
2. Set the number of engines.
3. Set the maximum tachometer range.
Preset engine monitor panels
The engine application has 5 preset panels, each of which provides
a particular category of engine data.
To select a preset engine monitor panel
1. Press the ACTIVE button.
2. Press the appropriate softkey.
Temperature and fuel units
Engine temperature units (
°
F or
°
C) and fuel units (liters, imperial
gallons or US gallons) are defined in the System Setup Menu under
Units Setup.
Engine monitor alarms
The engine monitor triggers an alarm (over NMEA/SeaTalk
ng
) when
a problem is detected.
If this occurs, check the engine monitoring system and if necessary
refer to the documentation supplied with your engine system. Press
ACKNOWLEDGE to silence the alarm.
Note: When engine monitoring is active, all other system alarms
remain active.
Panel Type
Data content
Tacho &
engine hours
Oil pressure
Engine coolant
temperature
Boost
pressure
Alternator
Fuel level
(tanks 1 & 2)
Fuel rate
Total fuel
Engine
Engine
& fuel
Fuel
resources
Engine &
resources
Twin
engines
81314-1_A Series Reference Guide.book Page 122 Thursday, August 28, 2008 9:23 AM
