58 A-Series display - User reference manual
Panoramic and aerial photographs
Requires navionics chart card with aerial photography.
In some regions an aerial photo overlay is available to enhance your
chart view. The overlay covers navigable waters and an area up to 3
miles from the coast including US lakes and inland waters.
The availability of a panoramic photograph is indicated on the chart
by the camera icon. This is placed on the chart at the point the pho-
tograph was taken, with the viewpoint indicated by the angle of the
icon.
To show a panoramic photograph:
1. Use the trackpad to move the cursor over the camera icon.
2. Press OK. The panoramic photograph appears.
or,
1. Use the trackpad to move the cursor over a port symbol.
2. Press OK. The port information dialog box appears.
3. Use the trackpad to highlight PHOTOS.
4. Select a numbered photograph from the list.
5. Press the VIEW PHOTO soft key.
To overlay aerial photography:
1. Press the PRESENTATION soft key.
2. Press the CHART LAYERS soft key.
3. Toggle AERIAL OVERLAY to ON or OFF as required.
4. Use the trackpad Left / Right to set the overlay opacity.
Overlay area
You can choose whether the aerial overlay is shown for land areas
only, or for land and sea areas.
• On land shows a normal chart view for sea areas and overlays
aerial photography on areas of land. This can help interpret your
surroundings while keeping important navigational data visible.
• On land and sea shows aerial photography of both land and
sea areas. This can help in distinguishing between deep and
shallow water (dark blue and light blue, respectively), and to
view land features simultaneously.
The overlay area can be set up using the Aerial Photo Overlay func-
tions of the Cartographic Setup Menu.
To specify the overlay area
1. Open the Cartography Setup Menu.
2. Select Aerial Photo Overlay.
3. Choose your preferred setting.
81314-1_A Series Reference Guide.book Page 58 Thursday, August 28, 2008 9:23 AM
