20 A-Series display - User reference manual
2.6 Operation
Powering the display ON/OFF
To Power ON:
Press and hold the POWER key until the screen shows
the Raymarine logo. The unit starts up in the last used
display configuration.
To Power OFF:
Press and hold the POWER key until the power down
countdown reaches zero. The unit is powered OFF.
Releasing the POWER key before the countdown is com-
plete cancels the power off sequence.
Cursor
When you are using chart and fishfinder applications, the cursor is
used to move around the screen.
To move the cursor:
Press the trackpad in the direction you want the
cursor to move.
Cursor appearance
The cursor appears on the screen as a white cross.
If the cursor has not been moved for a short period of
time, it changes to a circle with a cross in it, to make it
easier to locate on screen.
The cursor is context-sensitive; when it is placed over
an object, e.g. a waypoint or chart feature, it changes
color and a label or information associated with the
object is shown. Placing the cursor over certain items
will also cause the softkeys to change, enabling you
to access related operations.
Panning and zooming
In the appropriate chart or fishfinder application windows, you can
pan and zoom the view to show a different geographic area (pan) or
change the scale at which an area is displayed (zoom).
To Pan the view
Use the trackpad to move the cursor to the edge of
the screen, The view automatically moves in the
selected direction to bring a different area into
view.
D7366_3
D7368_2
D7369-2
WPT
81314-1_A Series Reference Guide.book Page 20 Thursday, August 28, 2008 9:23 AM
