32 A-Series display - User reference manual
2. Using the trackpad move the cursor to the position where you
want the waypoint.
3. Press the WAYPOINT AT CURSOR softkey.
4. Press OK.
To place a waypoint at your boat’s position:
1. Press the WPTS/MOB button.
2. Press the WAYPOINT AT VESSEL softkey.
3. Press OK.
Note: If the system cannot determine your position, a warning is
displayed and the waypoint cannot be placed.
To place a waypoint using coordinates:
1. Press the WPTS/MOB button.
2. Press the WAYPOINT AT LAT/LON softkey.
3. Set the position for the new waypoint.
4. Press OK.
Navigating to waypoints
This section explains how to start and stop navigating to a waypoint.
When you navigate to a waypoint, the data is sent to your autopilot.
The waypoint to which you are navigating is the active waypoint.
Note: Autopilots must be compatible and connected to the A-
Series display as shown in the installation guide.
For detailed information on navigating with waypoints, see The chart
application on page 37.
To navigate to a waypoint
1. Highlight the waypoint.
2. Press the GOTO WAYPOINT softkey.
or
1. Press either the WPTS/MOB button or GOTO softkey.
2. Press the GOTO WAYPOINT OPTIONS softkey.
3. Select the appropriate waypoint from the list.
4. Press GOTO WAYPOINT.
To stop navigating to a waypoint
1. Highlight the waypoint.
2. Press the STOP GOTO softkey.
or
1. Press the WPTS/MOB button.
2. Press the GOTO WAYPOINT OPTIONS softkey.
3. Press the STOP GOTO softkey.
D8285_1
81314-1_A Series Reference Guide.book Page 32 Thursday, August 28, 2008 9:23 AM
