Chapter 4: The chart application 53
Motion mode options
• Relative motion (RM)
This is the default motion mode. In this mode the chart is re-
drawn relative to your boat’s position as your journey
progresses, so that your boat is always shown in the same place
on-screen.
• True motion (TM)
In this mode the chart view remains static and your boat is
shown moving across it as progress is made. As the boat’s posi-
tion approaches the edge of the screen, the chart area is
redrawn to show what is ahead of you.
Note: True motion cannot be selected if the orientation is set to
Head Up.
• Relative motion with vessel offset
In relative motion mode you have the option to specify the posi-
tion of your boat in relation to the chart view.
4.11 Chart detail
You can change the features and level of detail displayed on the
chart. For example you may wish to hide certain features if there are
many objects displayed in a small geographic area.
Show / Hide waypoints, routes and tracks
There are a number of options to show / hide various aspects of the
waypoint, route and track information.
To show or hide waypoints by group or symbol
1. Press the PRESENTATION softkey.
2. Press SHOW/HIDE WAYPOINTS.
3. Toggle between SYM and GROUP on the SHOW BY softkey.
4. Select the relevant group and toggle its setting to SHOW or HIDE
on the ON CHART softkey.
To show or hide waypoint names
1. Press the PRESENTATION softkey.
2. Press SHOW/HIDE WAYPOINTS.
3. Toggle to the required setting with the WAYPOINT NAME
softkey.
To show or hide waypoint index numbers
1. Press the ROUTES softkey.
2. Press SHOW/HIDE ROUTES.
3. Toggle settings with the WAYPOINT INDEX softkey.
To show or hide routes and tracks
1. Highlight a route or track and press the HIDE softkey.
81314-1_A Series Reference Guide.book Page 53 Thursday, August 28, 2008 9:23 AM
