Connecting the Machine
This section gives instructions for connecting the machine and computer using
the parallel port and the optional USB port.
Reference
For Ethernet and IEEE 1394 interface connections, see “Connecting the Ma-
chine (Network Connections)”, General Settings Guide.
Requirements
Before using this machine, make sure all environmental and electrical require-
ments met. Connect the machine to the host computer using the parallel port,
network interface unit, or both.
Make sure all cables, connectors, and electrical outlets necessary to attach the
machine to the host computer or network are present.
Connecting the Machine to the Host Using the Parallel Cable
Connect the machine to the host computer using the parallel port. This machine
does not come with a parallel cable to connect the machine to the host computer.
The machine's parallel interface is a standard bidirectional interface. It requires
a standard IEEE 1284 compliant 36-pin parallel cable and a parallel port on the
host computer. Make sure to purchase the appropriate cable for the machine and
your computer.
Note
❒ Do not use a parallel cable that is longer than 3 meters (10 feet).
❒ Rating voltage of the interface connector: Max. DC 5V
Follow the procedures below to connect the machine to the host computer using
a parallel cable.
Important
❒ Before connecting the machine and a computer using an interface cable, make
sure that the machine is not operating, and then turn off the main power
switches of the machine and computer.
❒ Be sure to use the designated interface cable. Other cables may cause radio in-
terference.
A
AA
A
Turn off the main power switch.
Important
❒ Before turning off the main power switch, see “Turning Off the Power”,
General Settings Guide.
