NetWare Configuration
72
5
E
EE
E
Click the IPX address of the Network Interface Board which is to be config-
ured, and then click [Next >].
Note
❒ If you do not know which Network Interface Board you are configuring,
see the network configuration page to check the MAC address (Network
Address).
F
FF
F
Make sure that the MAC address and IPX address are correct, and then click
[Finish].
The [NIB Setup Tool] window appears.
G
GG
G
Click [Configure].
The property sheet appears.
H
HH
H
Click the [General] tab, and then type the name of the print server into the
[Device Name] box.
I
II
I
Click the [NetWare] tab, and then make the following settings.
NetWare 3.x
A In the [Print Server Name] box, type the name of the print server.
B In the [File Server Name] box, type the name of the file server in which a
print server is to be created.
Clicking [Browse], you can select a file server among those listed in the
[Browse] dialog box.
C In the [Print Server Operation Mode] group, click [As Remote Printer].
D In the [Remote Printer No.] box, type the printer number.
Important
❒ Use the same printer number as that to be created in the printer server.
E Click [OK] to close the property sheet.
F After the confirmation dialog box appears, click [OK].
NetWare 4.x, 5/5.1
A In the [Print Server Name] box, type the name of the print server.
B In the [File Server Name] box, type the name of the file server in which a
print server is to be created.
Clicking [Browse], you can select a file server among those listed in the
[Browse] dialog box.
To Next Page
