3. Push the paper tray carefully into the printer until it stops.

• For details about types of paper supported by this printer, see p.101 "Supported Paper for Each

Tray".

Specifying a paper type

This section describes how to specify a paper type. You can improve printer performance by selecting the

optimum paper type for the tray.

1. Press the [Menu] key.

BMW028S

2. Press the [ ] or [ ] key to select [Paper Input], and then press the [OK] key.

Loading Paper

127
