Paper Misfeed Message (C)
The " C Read instructions in Front Cover to remove." error message appears when a paper misfeed occurs
in the paper feed section.
• The inside of this printer becomes very hot. Before removing paper around the fusing unit, wait until
the temperature of the covers inside the fusing unit and duplex unit cool down.
• When removing misfed paper from the fusing unit, do not touch any parts other than those specified
in this manual.
• When a paper misfeed (C) occurs, the paper tray is locked and cannot be pulled out. Do not forcefully
pull out the tray.
1. Push up the lever on the right side, and open the printer's right cover carefully.
BMV103S
2. Loosen the screws to remove the brackets from both sides of the fusing unit.
BMV257S
10. Removing Misfed Paper
236
10
