Replacing the Transfer Roller

1. The transfer roller is installed as shown below.

BMW019S

2. Holding the green grips on both sides, pull up the transfer roller.

BMW020S

3. Holding the green grips, pull out the transfer roller from the printer.

BMW021S

Replacing the Fusing Unit, Transfer Roller, and Dustproof Filter

165
