When the 2 Tray Finisher is Installed

When R1, R2, R3, or R4 is displayed.

1. Open the front cover of the finisher.

BEK110S

2. Turn lever R1 counterclockwise.

BEK066S

3. Open lever R3.

BEK067S

10. Removing Misfed Paper

248
