2. Installing Options
This chapter explains how to install various options for this printer.
Available Options
By installing options, you can improve printer performance and expand the available features.
• Before installing options, the machine should be turned off and unplugged for at least an hour.
Components inside the machine become very hot, and can cause a burn if touched.
Order of Option Installation
When installing multiple options, the following order is recommended:
1. Attach the 500-sheet paper feed unit
The 500-sheet paper feed unit can be used in combination with the 1000-sheet paper feed unit. In
this case, attach the 500-sheet paper feed unit to the 1000-sheet paper feed unit before attaching
to the printer.
2. Attach the 1000-sheet paper feed unit or 2000-sheet paper feed unit
Either the 1000-sheet paper feed unit or 2000-sheet paper feed unit can be attached, but not both.
3. Install the SDRAM module
Install in the slot inside the controller board.
4. Install the hard disk
Install inside the controller board.
5. Install the Gigabit Ethernet board
Install inside the controller board.
6. Install the interface board
Install in the slot of the controller board.
Only one interface board can be installed.
7. Insert SD card options
Insert in the SD card slot of the controller board.
There are two slots for SD cards.
Each slot supports different types of SD cards.
If you want to use two or more SD cards that can be inserted in the same slot, contact your sales or
service representative.
31
