SERVICE MODE TABLE
SM 5-11 G104
Service
Tables
1001 036 Tray 3: Thick 2 *EGB [-10.0 to 10.0 / 1.5 / 0.1 mm/step]
1001 037 Tray 3: Thin: LS *EGB [-10.0 to 10.0 / 0.0 / 0.1 mm/step]
1001 038 Tray 3: Thin: RS *EGB [-10.0 to 10.0 / 0.0 / 0.1 mm/step]
1001 039 Tray 3: Special *EGB [-10.0 to 10.0 / 1.5 / 0.1 mm/step]
1001 040 By-pass: N2: LS *EGB [-10.0 to 10.0 / 1.0 / 0.1 mm/step]
1001 041 By-pass: N2: RS *EGB [-10.0 to 10.0 / 1.0 / 0.1 mm/step]
1001 042 By-pass: Thick 2 *EGB [-10.0 to 10.0 / 1.5 / 0.1 mm/step]
1001 043 By-pass: Thin: LS *EGB [-10.0 to 10.0 / 0.0 / 0.1 mm/step]
1001 044 By-pass: Thin: RS *EGB [-10.0 to 10.0 / 0.0 / 0.1 mm/step]
1001 045 By-pass: Special *EGB [-10.0 to 10.0 / 1.5 / 0.1 mm/step]
1002 [S-to-S Reg.] Side-to-Side Registration
1002 001 By-pass *EGB
1002 002 Tray 1 *EGB
1002 003 Tray 2 *EGB
1002 004 Tray 3 *EGB
1002 005 Duplex *EGB
Adjusts the side-to-side registration for each
mode. This SP changes the laser main scan
start position.
[-10.0 to 10.0 / 0.0 / 0.1 mm/step]
1003 [Paper Buckle] Paper Buckle
(Tray or By-pass, Paper Type, Process Speed)
Paper Type ->N: Plain paper 1, N2 or Normal 2: Plain paper 2, Thick2: Thick
paper 2 (see the Specifications table for details on these paper weights)
Process Speed-> LS: Low speed, RS: Regular speed
1003 001 Tray 1: Normal: LS *EGB
1003 002 Tray 1: Normal: RS *EGB
1003 003 Tray 1: Thick *EGB
1003 004 Tray 1: OHP *EGB
1003 005 Tray 2: Normal: LS *EGB
1003 006 Tray 2: Normal: RS *EGB
1003 007 Tray 2: Thick *EGB
1003 008 Tray 2: OHP *EGB
1003 009 Tray 3: Normal: LS *EGB
1003 010 Tray 3: Normal: RS *EGB
1003 011 Tray 3: Thick *EGB
1003 012 Tray 3: OHP *EGB
1003 013 By-pass: N:LS *EGB
1003 014 By-pass: N:RS *EGB
1003 015 By-pass: Thick *EGB
1003 016 By-pass: OHP *EGB
1003 017 Duplex: Normal: LS *EGB
1003 018 Duplex: Normal: RS *EGB
1003 019 Duplex: Thick *EGB
1003 020 Duplex: N2: LS *EGB
1003 021 Duplex: N2: RS *EGB
1003 022 Tray 1: Normal 2: LS *EGB
1003 023 Tray 1: Normal 2: RS *EGB
1003 024 Tray 1: Thick 2 *EGB
1003 025 Tray 1: Thin: LS *EGB
Adjusts the amount of paper buckle at the
registration roller for each mode. This SP
changes the paper feed timing.
[-10.0 to 10.0 / 0.0 / 0.1 mm/step]
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
