ENGINE SERVICE MODE
SM 5-71 G104
Service
Tables
SP7-XXX (Data Log)
7002 [Total Counter]
7002 001 Color Counter *EGB
7002 002 Black Counter *EGB
Displays the value of the counters.
[0 to 9999999 / 0 / 1/sheet]
7401 [SC Counter]
7401 001 *CTL Displays the number of SC codes detected.
[0 to 9999 / 0 / 1/step]
7403 [Latest10SClog]
7403 001 Latest *CTL
7403 002 Latest 1 *CTL
7403 003 Latest 2 *CTL
7403 004 Latest 3 *CTL
7403 005 Latest 4 *CTL
7403 006 Latest 5 *CTL
7403 007 Latest 6 *CTL
7403 008 Latest 7 *CTL
7403 009 Latest 8 *CTL
7403 010 Latest 9 *CTL
Logs the SC codes detected.
The 10 most recently detected SC Codes are
not displayed on the screen, but can be seen
on the SMC (logging) outputs.
7502 [Total Jam]
7502 001 *CTL Displays the total number of jams detected.
[0 to 9999 / 0 / 1 sheet/step]
[Jam Location] 7504
Displays the number of jams according to the location where jams were
detected.
7504 001 Main 001 *CTL Not used
7504 003 Main 003 *CTL Tray 1: ON
7504 004 Main 004 *CTL Tray 2: ON
7504 005 Main 005 *CTL Tray 3/LCT: ON
7504 006 Main 006 *CTL Tray 4: ON
7504 008 Main 008 *CTL Registration: ON
7504 009 Main 009 *CTL External Tray: ON
7504 010 Main 010 *CTL Internal Tray: ON
7504 011 Main 011 *CTL Duplex: ON
7504 012 Main 012 *CTL Duplex Exit 1: ON
7504 013 Main 013 *CTL Duplex Exit 2: ON
7504 015 Main 015 *CTL Optional paper tray unit feed: ON
7504 061 Main 061 *CTL Registration: OFF
7504 063 Main 063 *CTL External Tray: OFF
7504 065 Main 065 *CTL Duplex: OFF
7504 066 Main 066 *CTL Duplex Exit 1: OFF
7504 070 Main 070 *CTL Not used
7504 071 Main 071 *CTL Not used
