SPECIFICATIONS
G104 7-2 SM
First Print Speed: Color: 15 seconds or less (from tray 1)
Black & White: 10 seconds or less (from tray 1)
Warm-up Time
Less than 30 seconds (at 23°C/50%)
Print Paper Capacity:
(80 g/m2, 20lb)
Standard tray: 550 sheets
By-pass tray: 100 sheets
Optional paper feed tray: 550 sheets
Print Paper Size: (Refer to “Supported Paper Sizes”.)
Minimum Maximum
Standard Tray A4 / B5 / 81/2" 11" / 81/2" x 14" (SEF)
By-pass 90 x 148 mm 216 x 356 mm
Optional Tray A4 / B5 / 81/2" x 11" / 81/2" x 14" (SEF)
Printing Paper
Weight:
Standard tray, Optional paper tray, and bypass tray
One-sided: 52-216 g/m
2
(16-55 lb)
Duplex: 60-157 g/m
2
(16-43 b)
Paper weight settings at printer driver and operation panel:
Thin: 52 – 60.2 g/m
2
Plain paper 1 (Plain): 60.2 – 90.2 g/m
2
Plain paper 2 (Plain & Recycled): 90.2 – 104.7 g/m
2
Thick paper 1: 104.7 – 157 g/m
2
Thick paper 2: 157 – 216 g/m
2
Output Paper
Capacity:
Standard exit tray: 500 sheets (face down)
Memory:
Standard 128/ 256 MB, up to 512 MB with optional Memory
Unit
Power Source: 120 V, 60 Hz: More than 11 A (for North America)
220 V - 240 V, 50/60 Hz: More than 6 A (for Europe/Asia)
Power Consumption:
120 V 220-240 V
Maximum 990 W or less 1200 W or less
Energy Saver 6 W or less 6 W or less
Noise Emission:
(Sound Power Level)
Mainframe Only Full System
Printing 63 dB or less 67 dB or less
Stand-by 40 dB or less 40 dB or less
NOTE: The above measurements were made in accordance with ISO9296 at the
operator position.
Dimensions (W x D x H):446 x 589.5 x 487 mm (17.4" x 23.2" x 19.2")
Weight: Less than 50 kg (110.3 lb.)
