Service Mode Table
SM 5-163 G160/G161
G160/G161
5804 009 Exit Paper Fan H Paper Exit Fan: High speed
5804 010 Polyg. Mir. Motor Polygon Mirror Motor
5804 011 Exit Paper Fan L Paper Exit Fan: Low speed
5804 012 Duplex Fan Duplex Motor
5804 020 Paper Feed Motor Paper Feed/ Fusing Motor
5804 022 Mono. PCU Motor Black OPC/ Development Motor
5804 024 Color PCU Motor Color OPC Motor
5804 026 Color Dev. Motor Color Development Motor
5804 030 [Y] Toner Motor Toner Supply Motor [Y]
5804 031 [C] Toner Motor Toner Supply Motor [C]
5804 032 [M] Toner Motor Toner Supply Motor [M]
5804 033 [K] Toner Motor Toner Supply Motor [K]
5804 034 T. Belt Contact M Transfer Belt Contact Motor
5804 035 T. Roll 2 Contact M Transfer Roller Contact Motor
5804 036 LDU Shutter Motor LDU Shutter Motor
5804 040 Trans. Belt Motor Transfer Belt Unit Motor
5804 042 Duplex In Motor Inverter Motor
5804 044 Duplex Exit Motor Duplex Motor
5804 060 Paper Feed Clutch Paper Feed Clutch
5804 061 Relay Clutch Relay Transport Clutch
5804 062 Regist. Clutch Registration Clutch
5804 063 Develop. Clutch Development Clutch
5804 064 By-pass Solenoid By-pass Solenoid
5804 065 Duplex Solenoid Junction Gate Solenoid
5804 100 [Y]: Charge DC Charge Roller DC: Yellow PCU
5804 102 [C]: Charge DC Charge Roller DC: Cyan PCU
5804 104 [M]: Charge DC Charge Roller DC: Magenta PCU
5804 106 [K]: Charge DC Charge Roller DC: Black PCU
5804 110 [Y]: Charge AC Charge Roller AC: Yellow PCU
5804 112 [C]: Charge AC Charge Roller AC: Cyan PCU
5804 114 [M]: Charge AC Charge Roller AC: Magenta PCU
5804 116 [K]: Charge AC Charge Roller AC: Black PCU
5804 118 Charge AC Trigger Charge Roller AC Trigger
5804 120 [Y]: Develop. DC Development DC: Yellow
