Installation
Unpacking and Inspection
176 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Unpacking and Inspection
The QuickStick HT transport system components are shipped in separate packages. Open
each package carefully following the steps that are provided in Unpacking and Moving on
page 177; inspect and verify the contents against the shipping documents. Report any damage
immediately to the shipper and to MagneMotion.
One set of shipping documents is attached to the outside of the main shipping crate for easy
access.
NOTE: The number and contents of the shipping packages depends on the items purchased.
See the shipping documents for the exact contents. The checklist in Table 5-1 is pro-
vided for reference only.
Table 5-1: QuickStick HT Packing Checklist Reference
Package Contents
QuickStick HT Motors QuickStick HT linear synchronous motors.
Motor Drives Controllers or inverters for the QSHT motors.
Magnet Arrays Magnet arrays to be attached to the vehicles as the motor second-
ary to provide material movement on the transport system.
Node Controllers MagneMotion node controllers for managing the nodes in the
transport system.
Power Supplies Power supplies to provide logic and propulsion power to the
QuickStick HT motors.
Installation Kit • Miscellaneous hardware.
• Cables.
• User Manuals, drawings, and so on.
