EXHAUST SYSTEM 6-3
INSPECTION
HO2 SENSOR (#4-60)
INSTALLATION
Install the exhaust pipe and muffler in the reverse order of
removal. Pay attention to the following points:
• Apply gas sealer to the muffler connector

1.
EXHAUST GAS SEALER:
PERMATEX 1372 (commercially available)
"
• Install the exhaust pipe gasket

2.
"
• Tighten the exhaust pipe nuts

3, muffler mounting bolts

4,
muffler connecting bolts

5 and HO2 sensor

6 to the speci-
fied torque.
$ Exhaust pipe nut: 23 N·m (2.3 kgf-m)
Muffler mounting bolt: 23 N·m (2.3 kgf-m)
Muffler connecting bolt/nut: 23 N·m (2.3 kgf-m)
HO2 sensor: 48 N·m (4.8 kgf-m)
Replace the muffler connector with a new one.
Replace the exhaust pipe gasket with a new one.
