4-9
FUEL
AND
LUBRICATION
SYSTEM
CHOKE CABLE
• Refer
to
page
2-6.
• Actuator,
throttle
and oil pump cable adjustment.
• Refer
to
page
3-11.
OIL
PUMP
BLEEDING AIR FROM THE OIL
PUMP
CIRCUIT
Whenever evidence
is
noted
of
some
air
having leaked
into
the
oil pipe
from
the oil tank in a machine brought in
for
servicing,
or
if
the
oil
pump
has
to
be
removed
for
servicing,
be
sure
to
carry
out
an
air bleeding operation
with
the oil pump in place
before returning the machine
to
the
user.
To
bleed the air, hold the machine in standstill condition.
Loosen the screw
CD
to
let
out
the air and after making
sure
that
the trapped air
has
all
been
bled, tighten the screw good
and hard.
CHECKING OIL
PUMP
Use
the special tool, and check the pump
for
capacity
by
measuring the amount
of
oil the pump draws during the
speci-
fied interval.
•
Have
the
tool
filled
with
SUZUKI
CCI
or
CCI
SUPER
01
L
and connect
it
to
the suction
side
of
the pump.
• Run the engine at 2 000 r/min.
