Copying and Printing Copy Setup: Waveforms
To use
1. Select the Palette for the image:
Color
Color (Ink Saver Mode)
Black & Whit
e
2. Select the type of View:
Full Screen. Copies an image of the entire screen.
Graticule(s) Only. Copies an image of the selected graticule.
3. Click the Hide Menu/Toolbar check box to save the image without including the Menu bar or Toolbar.
4. Click OK.
Behavior
The Palette, View, and Image selections are identical to those in the Page Setup dialog box and in the
Screen Capture Save Options dialog box.
The copy operation takes place after you click Copy. Clicking OK saves the changes and closes the
dialog box but does not copy the image.
NOTE. Bitmap (.bmp) is the only available Data Format.
What do you want to do next?
Learn about copying waveforms. (see page 514)
Learn about copying measurements. (see page 516)
Le
arn about saving images to a file.
(see page 534)
Copy Setup: Waveforms
From the Edit menu, select Copy Setup; then open the Waveforms tab.
Overview
Use this control window to copy waveforms to the clipboard for use with other applications.
514 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
