File Menu Save As Dialog Box: Screen Capture
7. Select the type of file (either .txt or .csv) to save from the Save as type list. By default, the file will be
saved to the
C:\Users\[Username]\Tektroni x\TekScope\Data folder.
8. Click the Save button to accept any changes and close the dialog box.
Behavior
When you select Displayed Measurements, all displayed measurements are saved.
What do you want to do next?
Learn about saving waveforms. (see page 537)
Learn about saving screen captures. (see page 534)
Learn more a bout CSV text format. (see page 885)
Save As Dialog Box: Screen Capture
From the File menu, highlight Save As; then select Screen Capture from the submenu.
Overview
Use this dialog box to save screen captures to a file for use with other applications.
534 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
