Toshiba TOSVERT VF-nC3E User Manual

E6582233
F-6
6
6.2.2 Changing the functions of VI terminal
 : Analog/logic input selection (VI terminal)
 Function
This parameter allows you to choose between analog input and logic input for the VI terminal.
[Parameter setting]
Title Function Ad
j
ustment ran
g
e Default settin
g

Analog/logic input
selection (VI terminal)
0: Voltage signal input (0 - 10V)
1: Current signal input (4 - 20mA)
2: Logic input
3: Volta
g
e si
g
nal input
(
0 - 5V
)
0
★ Resolution is maximum 1/1000 when VI terminal is used as analog input terminal (,,).
* In sink logic connection, be sure to insert a resistor between the P24 terminal and the VI terminal, when
using it as the logic input terminal. Refer to section 2.3.2 for details (page B-12).
* For information about the interface with the programmable controller, refer to section 7.2.1 (page G-3).
