E6582233
F-68
6
6.20.8 Parameter registration to easy setting mode
- : Easy setting mode parameter 1 to 24
Up to 24 arbitrary parameters can be registered to easy setting mode.
Refer to section 4.4 for details.
6.21 Communication function (RS485)
: Baud rate : Block write data 1
: Parit
: Block w
ite data 2
: Inverter numbe
: Block read data 1
: Communication time-out time : Block read data 2
: Communication time-out action : Block read data 3
: Communication time-out
detection condition
: Block read data 4
: Selection of communication
protocol
: Block read data 5
Warning
Mandatory
action
Set the parameter Communication time-out time (f803) and Communication time-out action (f804).
If these are not properly set, the inverter cannot be stopped immediately in breaking communication and
this could result in injury and accidents.
An emergency stop device and the interlock that fit with system specifications must be installed.
If these are not properly installed, the inverter cannot be stopped immediately and this could result in
in
ur
and accidents.
Refer to the Communications Function Instruction Manual (E6581657) for details.
Function
2-wire RS485 communication is built-in as standard.
Connect with the host to create a network for transmitting data between multiple inverters. A computer
link function is available.
<Computer-linking functions>
The following functions are enabled by data communication between the computer and inverter
(1) Monitoring inverter status (such as the output frequency, current, and voltage)
(2) Sending RUN, STOP and other control commands to the inverter
(3) Reading, editing and writing inverter parameter settings
Timer function …Function used to detect cable interruptions during communication.
When data is not sent even once to the inverter during a user-
defined period of time, an inverter trip ( is displayed on the
panel) or an output terminal alarm can be output.
Broadcast communication function …Function used to send a command (data write) to multiple
inverters with a single communication.
