E6582233
F-60
6
6.19.2 Calibration of analog output
 : Analog output signal selection
 : Inclination characteristic of analog output
 : Analog output bias
 Function
Output signal from the FM terminal can be switched between 0 to 1mAdc output, 0 to 20mAdc output,
and 0 to 10Vdc output with the  setting. The standard setting is 0 to 1mAdc output.
* Optional frequency meter: When using QS6T, set = (meter option (0 to 1mA) output).
[Parameter setting]
Title Function Ad
j
ustment ran
g
e Default settin
g
 Analog output signal selection
0: Meter option (0 to 1mA)
1: Current (0 to 20mA) output
2: Volta
g
e
(
0 to 10V
)
outpu
t
0

Inclination characteristic of analog
outpu
t
0: Negative inclination (downward slope)
1: Positive inclination
(
upward slope
)
1

Analog output bias -1.0 - +100.0% 0
Note 1: With 0 to 20mAdc (4 to 20mAdc) output, or 0 to 10Vdc output, set  to  or .
 Example of setting
=1, =1, =0(%) =1, =1, =20(%)
0
20
(mA)
0100%
Output current
Internal calculated value
4
20
(mA)
0 100%
f692
Output current
Internal calculated value
=1, =0, =100(%) =1, =0, =100(%)
0
20
(mA)
0 100%
: Large gain
Output current
Internal calculated value
4
20
(mA)
0 100%
: Small gain
f692
Output current
Internal calculated value
★ The analog output inclination can be adjusted using the parameter .
