Toshiba TOSVERT VF-nC3E User Manual

E6582233
F-71
6
 Communication function settings
Commands and frequency settings are given priority by communication. (Prioritized by commands from the
panel or terminal block.) Thus, command and frequency settings from communication are activated,
regardless of the command mode selection () or frequency settings mode selection settings ().
However, setting 48: SCLC (switching from communication to local) with input terminal function selection and
when inputting from an external device, it is possible to operate at command mode selection () and
frequency setting mode selection () settings.
Moreover, connecting the optional extension panel and selecting local mode with the LOC/REM key changes
to panel frequency/panel operation mode.
 Transmission specifications
Item Specifications
Interface RS485 compliant
Transmission path configuration
Half duplex [Serial bus type (Line terminations resistor necessary at
both ends of s
y
stem
)
]
Wiring 2-wire
Transmission distance 500 m max. (total length)
Connection terminals
32max. (including upper host computer) Inverters connected in the
s
y
stem: 32max.
Synchronization Asynchronous
Transmission speed
Default: 19200 bps (parameter setting) 9600/19200/38400 bps
selectable
Transmission character
ASCII mode … JIS X 0201 8-bit (ASCII)
Binar
y
code … Binar
y
code, 8-bit fixed
Stop bit length Received by inverter : 1 bit / Sent by inverter : 2 bits
Error detection
Battery Even number/odd number/non Selection (parameter setting),
checksum
Error correction None
Response monitoring None
Transmission character type 11 bit characters (Stop bit =1 , with parity)
Other
Inverter operation at communication time-over: Select from
trip/alarm/none
→ When alarm is selected, an alarm is output from the output
terminal.
When trip is selected,  blinks on the panel.
