Toshiba TOSVERT VF-nC3E User Manual

E6582233
J-1
10
10. Table of parameters and data
10.1 Frequency setting parameter
Title Function Unit
Minimum setting unit
Panel/Communication
Adjustment range
Default
setting
User
setting
Reference

FC Operation
frequency of
operation panel
Hz 0.1/0.01 - 0.0 3.1.2
10.2 Basic parameters
 Four navigation functions
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

AUH - History function - - Displays parameters in groups of five
in the reverse order to that in which
their settings were changed.
* (Possible to edit)
- 4.3
5.1

AUF 0093 Guidance function - - 0: -
1: -
2: Preset speed guidance
3: Analog signal operation guidance
4: Motor 1 & 2 switching operation
guidance
5: Motor constant setting guidance
0 4.3
5.2

AU1 0000 Automatic
acceleration/
deceleration
- - 0: Disabled (manual setting)
1: Automatic
2: Automatic (only at acceleration)
0 5.3

AU2 0001 Torque boost
setting macro
function
- - 0: -
1: Automatic torque boost + auto-
tuning
2: Vector control + auto-tuning
3: Energy saving + auto-tuning
0 5.4
 Basic parameters
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

CMOD 0003 Command mode
selection
- - 0: Terminal board
1: Panel keypad (including extension
panel)
2: RS485 communication
1 3
5.5
7.3

FMOD 0004 Frequency setting
mode selection
- - 0: Terminal board VI
1: Setting dial 1
(press in center to save)
2: Setting dial 2
(save even if power is off)
3: RS485 communication
4: -
5: UP/DOWN from external logic input
2 3
5.5
6.6.1
7.3
