Toshiba TOSVERT VF-nC3E User Manual

E6582233
I-1
9
9. Peripheral devices
Warning
Mandatory
action
 When using switchgear for the inverter, it must be installed in a cabinet.
Failure to do so can lead to risk of electric shock and can result in death or serious injury.
Be Grounded
 Connect grounding cables securely.
Failure to do so can lead to risk of electric shock or fire in case of a failure or short-circuit or electric
leak.
9.1 Selection of wiring materials and devices
 Selection of cable size
Voltage class
Applicable
motor (kW)
Cable size (mm
2
) (Note 4)
Power circuit
(Note 1, 5)
Braking resistor
(optional)
Grounding cable
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
3 phase
400V class
0.4 1.5 2.0 - - 2.5 2.0
0.75 1.5 2.0 - - 2.5 2.0
1.5 1.5 2.0 1.5 2.0 2.5 2.0
2.2 1.5 2.0 1.5 2.0 2.5 2.0
3.7 2.5 2.0 1.5 2.0 2.5 2.0
5.5 4.0 2.0 1.5 2.0 4.0 3.5
7.5 6.0 3.5 2.5 2.0 6.0 3.5
11 10.0 5.5 4.0 2.0 10.0 5.5
Note 1: Sizes of the wires connected to the input terminals R/L1, S/L2 and T/L3 and the output terminals U/T1,
V/T2 and W/T3 when the length of each wire does not exceed 30m.
Note 2: For the control circuit, use shielded wires 0.75 mm
2
or more in diameter.
Note 3: For grounding, use a cable with a size equal to or larger than the above.
Note 4: The cable sizes specified in the above table apply to HIV cables (copper cables shielded with an insulator
with a maximum allowable temperature of 75°C) used at an ambient temperature of 50°C or less.
