E6582233
K-4
11
11.2 Outside dimensions and mass
ï‚¢ Outside dimensions and mass
Voltage class
Applicable motor
(kW)
Inverter type
Dimensions (mm)
Drawing
Approx. weight
(kg)
W H D W1 H1 H2
0.4 VFNC3E-4004P
72 130
130
60 118 13 A 0.8
0.75 VFNC3E-4007P 140
1.5 VFNC3E-4015P
105 130 151 93 118 13 B 1.2
2.2 VFNC3E-4022P
3.7 VFNC3E-4037P
140 171 151 126 157 13 C
1.9
5.5 VFNC3E-4055P 2.0
7.5 VFNC3E-4075P
150 220 171 130 210 12 D
3.6
11 VFNC3E-4110P 3.8
Note 1. To make it easier to grasp the dimensions of each inverter, dimensions common to all inverters in these
figures are shown with numeric values but not with symbols.
Here are the meanings of the symbols used.
W: Width
H: Height
D: Depth
W1: Mounting dimension (horizontal)
H1: Mounting dimension (vertical)
H2: Height of Grounding terminal area
Note 2. The models shown in Fig. A to Fig. B are fixed at two points: in the upper left and lower right corners.
Note 3. The model shown in Fig. A is not equipped with a cooling fan.
Note 4. Height measurements do not include the protuberance for installation.
