Toshiba TOSVERT VF-nC3E User Manual

E6582233
I-5
9
(1)
Input AC reactor
(ACL)
Molded-case circuit breaker
MCCB
Power supply
Magnetic contactor
MC
Zero-phase reactor
core-type
radio noise
reduction filter
N.F
N.F
Inverter
(2)
M
(3)
Braking resistor
Motor
Zero-phase reactor
core-type
radio noise
reduction filter
(2)
(4)
Motor-end surge voltage
suppression filter
(for 400V models only)
9.4 Optional external devices
The following external devices are optionally available for this inverter series.
(5) Extension panel : RKP007Z
(6) Remote control panel : CBVR-7B1
(7) Frequency meter : QS6T
(8) FRH kit : FRH kit
(9) USB communication converter : USB001Z
