E6582233
E-2
5
Parameter
display
Press the MODE key to return to the parameter setting mode
“.”
After that you can press the MODE key to return to the status
monitor mode or the standard monitor mode (display of operation
frequency).
Note: The following parameters are not displayed in this auh, even if they are the most recent changes.
(Operation frequency of operation panel), (Guidance function), (Automatic
acceleration/deceleration), (Torque boost setting macro function), (Default setting),
(Prohibition of change of parameter settings)
5.2 Setting a parameter using the guidance function
: Guidance function
[Parameter setting]
Title Function Ad
ustment ran
e Default settin
Guidance function
0:-
1: - Note 1
2: Preset speed guidance
3: Analog signal operation guidance
4: Motor 1/2 switching operation guidance
5: Motor constant settin
uidance
0
Note: 1 is for manufacturer's settings. Do not change the settings.
MODE
MODE
MODE
Guidance function ():
The guidance function refers to the special function of calling up only functions necessary to set up the inverter in
response to the user’s needs. When a purpose-specific guidance is selected, a group of parameters needed for the
specified application (function) is formed and the inverter is switched automatically to the mode of setting the group
of parameters selected. You can set up the inverter easily by simply setting the parameters in the group one after
another. The guidance function () provides four purpose-specific guidance.
To Next Page
