10.4 Default settings by inverter rating
Inverter type
Torque
boost value
Dynamic
braking
resistance
Dynamic
braking
resistor
capacity
Automatic
torque
boost value
Motor rated
capacity
Motor rated
current
Motor
no-load
current
Integrating
wattmeter
display unit
selection
／

(%)

(Ω)
Note 1

(kW)
Note 1

(%)

(kW)

(A)

(%)

VFNC3E-4004P 6.0 200.0 0.12 6.2 0.40 1.0 65 0
VFNC3E-4007P 6.0 200.0 0.12 5.8 0.75 1.7 60 0
VFNC3E-4015P 6.0 200.0 0.12 4.3 1.50 2.4 55 0
VFNC3E-4022P 5.0 200.0 0.12 4.1 2.20 4.5 52 0
VFNC3E-4037P 5.0 160.0 0.12 3.4 3.70 7.4 48 1
VFNC3E-4055P 4.0 80.0 0.24 2.6 5.50 10.5 46 1
VFNC3E-4075P 3.0 60.0 0.44 2.3 7.50 14.1 43 1
VFNC3E-4110P 2.0 40.0 0.66 2.2 11.00 20.3 41 1
Note 1: Refer to Note 4 in 2) Optional dynamic braking resistors of section 6.13.4 for the parameter setting of f308
and f309.
