Toshiba TOSVERT VF-nC3E User Manual

E6582233
G-8
7
 Assign two types of functions to the output terminal (OUT)
Terminal
s
y
mbol
Title Function Adjustment range Default setting
OUT

Output terminal
selection 1A
0 - 255
4 (Low-speed detection
si
g
nal
)

Output terminal
selection 1B
255 (Always ON)

Output terminal logic
selection
0:  and 
1:  or 
0
Note 3)  and  are active only when  = : Logic output (default). 
Function is inactive when  = : Pulse train output is set.
(1) Output signals when two types of functions are simultaneously
turned ON.
Signals are output when parameter  is the default ( = 0), and the functions set at
parameters  and  are simultaneously turned ON.
☆ Timing chart
ON
OFF
ON
OFF
ON
OFF


OUT
Output
(2) Output signals when either one of two types of functions are
simultaneously turned ON.
Signals are output when parameter  = 1, and either of the functions set at parameters 
and  are turned on.
☆ Timing chart
ON
OFF
ON
OFF
ON
OFF


OUT
Output
