Toshiba TOSVERT VF-nC3E User Manual

E6582233
B-11
2 2
<Examples of connections when an external power supply is used>
Note 4) Be sure to connect 0V of external power supply and CC terminal of the inverter.
P24
CC
Note 4)
24VDC
F
Output
24VDC
OUT
NO
Input
Inverter
Programmable
controller
P24
Common
24VDC
OFF
（f127=200）
CC
F
24VDC
Output
Inverter
24VDC
ON
（f127=100）
24VDC
OUT
NO
Input
Programmable
controller
Input
Input
Output
Common
Common
Output
Common
Source (Positive) logic
f127=100
Sink (Negative) logic
f127=200
