124 Program features
Start/Stop control Selecting the source for start and stop
signals of the two external control
locations, EXT1 and EXT2
1001, 1002
Selecting between EXT1 and EXT2 1102
Defining the direction control 1003
Defining the start and stop modes 2101…2103
Selecting the use of Run enable signal 1601
Protections Setting the current and torque limits 2003, 2017
Output signals Selecting the signals indicated through
relay output RO1 and, if MREL-01 output
relay module is in use, RO2…RO4.
Group 14 RELAY
OUTPUTS
Selecting the signals indicated through
analog output AO
Setting the minimum, maximum, scaling
and inversion
Group 15 ANALOG
OUTPUTS
Timed functions Setting the timed functions Group 36 TIMED
FUNCTIONS
Selecting the timed start/stop control for
external control locations EXT1 and EXT2
1001, 1002
Selecting timed EXT1/EXT2 control 1102
Activation of timed constant speed 1 1201
Selecting timed function status indicated
through relay output RO1 or, if MREL-01
output relay module is in use, RO2…RO4.
1401…1403, 1410
Selecting timed PID1 parameter set 1/2
control
4027
Name Description Set parameters

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
