ABB ACS355 series User Manual

206 Actual signals and parameters
REF LOSS Reference or active control location is lost. 20
OVERCURRE
NT
Alarm/Fault by overcurrent protection function 21
OVERVOLTAG
E
Alarm/Fault by overvoltage protection function 22
DRIVE TEMP Alarm/Fault by drive overtemperature protection function 23
UNDERVOLTA
GE
Alarm/Fault by undervoltage protection function 24
AI1 LOSS Analog input AI1 signal is lost. 25
AI2 LOSS Analog input AI2 signal is lost. 26
MOTOR TEMP Alarm/Fault by motor overtemperature protection function.
See parameter 3005 MOT THERM PROT.
27
STALL Alarm/Fault by stall protection function. See parameter 3010
STALL FUNCTION.
28
UNDERLOAD Alarm/Fault by underload protection function. See
parameter 3013 UNDERLOAD FUNC.
29
PID SLEEP PID sleep function. See parameter group 40 PROCESS PID
SET 1 / 41 PROCESS PID SET 2.
30
FLUX READY Motor is magnetized and able to supply nominal torque. 33
USER MACRO
2
User macro 2 is active. 34
COMM Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
35
COMM(-1) Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
36
All parameters
No. Name/Value Description Def/FbEq
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 0 0 0 0 0
1 00001 0 0 0 0 1
2 00010 0 0 0 1 0
300011 0 0 0 1 1
4 00100 0 0 1 0 0
5…30… ……………
31 11111 1 1 1 1 1
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 1 1 1 1 1
1 00001 1 1 1 1 0
2 00010 1 1 1 0 1
300011 1 1 1 0 0
4 00100 1 1 0 1 1
5…30… ……………
31 11111 0 0 0 0 0

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
