ABB ACS355 series User Manual

Actual signals and parameters 303
AI1LO1AI2HI1 State change when AI1 value < par. 8412 SEQ VAL 1 LOW
value and AI2 value > par. 8411 SEQ VAL 1 HIGH value.
11
AI1LO1 ORDI5 State change when AI1 value < par. 8412 SEQ VAL 1 LOW
value or when DI5 is active.
12
AI2HI1 ORDI5 State change when AI2 value > par. 8411 SEQ VAL 1 HIGH
value or when DI5 is active.
13
AI 1 LOW 2 State change when AI1 value < par. 8414 SEQ VAL 2 LOW
value.
14
AI 1 HIGH 2 State change when AI1 value > par. 8413 SEQ VAL 2 HIGH
value.
15
AI 2 LOW 2 State change when AI2 value < par. 8414 SEQ VAL 2 LOW
value.
16
AI 2 HIGH 2 State change when AI2 value > par. 8413 SEQ VAL 2 HIGH
value.
17
AI1 OR 2 LO2 State change when AI1 or AI2 value < par. 8414 SEQ VAL 2
LOW value.
18
AI1LO2AI2HI2 State change when AI1 value < par. 8414 SEQ VAL 2 LOW
value and AI2 value > par. 8413 SEQ VAL 2 HIGH value.
19
AI1LO2 ORDI5 State change when AI1 value < par. 8414 SEQ VAL 2 LOW
value or when DI5 is active.
20
AI2HI2 ORDI5 State change when AI2 value > par. 8413 SEQ VAL 2 HIGH
value or when DI5 is active.
21
TIMED FUNC 1 Trigger with timed function 1. See parameter group 36
TIMED FUNCTIONS.
22
TIMED FUNC 2 See selection TIMED FUNC 1.23
TIMED FUNC 3 See selection TIMED FUNC 1.24
TIMED FUNC 4 See selection TIMED FUNC 1.25
CHANGE DLY State change after delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed.
26
DI1 OR DELAY State change after DI1 activation or after delay time defined
by parameter 8424 ST1 CHANGE DLY has elapsed.
27
DI2 OR DELAY See selection DI1 OR DELAY.28
DI3 OR DELAY See selection DI1 OR DELAY.29
DI4 OR DELAY See selection DI1 OR DELAY.30
DI5 OR DELAY See selection DI1 OR DELAY.31
AI1HI1 ORDLY State change when AI1 value > par. 8411 SEQ VAL 1 HIGH
value or after delay time defined by parameter 8424 ST1
CHANGE DLY has elapsed.
32
AI2LO1 ORDLY State change when AI1 value < par. 8412 SEQ VAL 1 LOW
value or after delay time defined by parameter 8424 ST1
CHANGE DLY has elapsed.
33
All parameters
No. Name/Value Description Def/FbEq

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
