ABB ACS800-67LC User Manual

Technical data 123
Type equivalence table
Fuses
 Main circuit AC fuses
All fuses are UL listed.
 Main circuit DC fuses
All fuses are UL listed.
Type Construction
Grid-side converter Rotor-side converter
Module type Module type
ACS800-67LC-1075/0575-7 2xR8i+1xR8i+1xLCL ACS800-104LC-0705-7+E205 ACS800-104LC-0705-7+E205
ACS800-67LC-1375/0575-7 2xR8i+1xR8i+1xLCL ACS800-104LC-0705-7+E205 ACS800-104LC-0705-7+E205
ACS800-67LC-1375/1125-7 2xR8i+2xR8i+1xLCL ACS800-104LC-0705-7+E205 ACS800-104LC-0705-7+E205
ACS800-67LC-1595/0865-7 3xR8i+2xR8i+1xLCL ACS800-104LC-0555-7+E205 ACS800-104LC-0555-7+E205
ACS800-67LC-2035/1125-7 3xR8i+2xR8i+1xLCL ACS800-104LC-0705-7+E205 ACS800-104LC-0705-7+E205
Type
I
n
(A)
Bussmann
type
MRP code
Microswitch for
the fuse
MRP code
ACS800-67LC-1075/0575-7 700 170M4467 3AUA0000081489
170H0069 58063690
ACS800-67LC-1375/0575-7 700 170M4467 3AUA0000081489
ACS800-67LC-1375/1125-7 1400 170M6467 3AUA0000062487
ACS800-67LC-1595/0865-7 1250 170M6466 3AUA0000062488
ACS800-67LC-2035/1125-7 1400 170M6467 3AUA0000062487
Type
I
n
(A)
Mersen type MRP code
Microswitch
for the fuse
MRP code
ACS800-67LC-1075/0575-7 700 PC31UD69V700TF 3AUA0000081747
MS3 V1-5 3AUA0000081746
ACS800-67LC-1375/0575-7 700 PC31UD69V700TF 3AUA0000081747
ACS800-67LC-1375/1125-7 1400 PC33UD69V1400TF 3AUA0000081748
ACS800-67LC-1595/0865-7 1250 PC33UD69V1250TF 3AUA0000081749
ACS800-67LC-2035/1125-7 1400 PC33UD69V1400TF 3AUA0000081748
Type AC fuse spare part kit
ACS800-67LC-1075/0575-7 3AUA0000081750
ACS800-67LC-1375/0575-7 3AUA0000081750
ACS800-67LC-1375/1125-7 3AUA0000081751
ACS800-67LC-1595/0865-7 3AUA0000081752
ACS800-67LC-2035/1125-7 3AUA0000081751
Type
I
n
(A)
Mersen type
Bussmann
type
MRP code pcs
ACS800-67LC-1075/0575-7 1100 PC73UD10C11CTF 170M6549 68736021 6
ACS800-67LC-1375/0575-7 1100 PC73UD10C11CTF 170M6549 68736021 6
ACS800-67LC-1375/1125-7 1100 PC73UD10C11CTF 170M6549 68736021 8
ACS800-67LC-1595/0865-7 800 PC73UD13C800TF 170M6546 68736005 10
ACS800-67LC-2035/1125-7 1100 PC73UD10C11CTF 170M6549 68736021 10
