124 Technical data
Notes:
• Larger fuses must not be used.
• Use always the fuses that are specified by ABB.
• The recommended fuses are for branch circuit protection per NEC as required for UL
approval.
• Make sure that fuses within a converter are made by the same manufacturer.
Dimensions and free space requirements
400 mm free space is needed above to allow opening of pressure relief lids (that open automatically upon arc
fault). Lids need at least 200 mm space to open.
150 mm free space is needed at the right-hand side for the control cable plug-in connectors.
115 mm free space is needed at the right or left hand side of the converter for the cooling pipe connections
(depending on which side the cooling connections are).
Losses, cooling data and noise
1) With 200 mm or 400 mm (option +C111) wide incoming cubicle
2) With power cabinet (option +C108 or +C109)
3) With DC chopper (option +D150)
4) With 400 mm wide incoming cubicle (option +C111) and DC chopper (option +D150)
5) With power cabinet (option +C108 or +C109) and DC chopper (option +D150)
Type Height (mm) Depth (mm)
Width (mm)
ICU 200 mm
ICU 400 mm
(+C111)
ACS800-67LC-1075/0575-7 2000 644 1600 1800
ACS800-67LC-1375/0575-7 2000 644 1600 1800
ACS800-67LC-1375/1125-7 2000 644 1800 2000
ACS800-67LC-1595/0865-7 2000 644 2000 2200
ACS800-67LC-2035/1125-7 2000 644 2000 2200
ACS800-67LC-
Losses kW
Maximum
total losses
1), 3), 4)
Maximum
total losses
2), 5)
Maximum
P
loss tot coolant
1), 3), 4)
Maximum
P
loss tot coolant
2), 5)
Maximum
P
loss tot air
1), 3), 4)
Maximum
P
loss tot air
2), 5)
1075/0575-7 27 31 26 30 0.5 0.6
1375/0575-7 30 34 29 33 0.6 0.7
1375/1125-7 40 45 40 44 0.8 0.9
1595/0865-7 44 50 43 49 0.9 1.0
2035/1125-7 57 63 56 62 1.1 1.3
ACS800-67LC-
Pressure loss kPa (bar)
1), 2), 3), 4, 5)
Noise level dB
1), 2), 3), 4, 5)
All types 100 (1.0) <70
