80 Electrical installation
Control connections
Control cable connections are described below
.
For location of the connectors, see page
33
.
Connector X1:
230
V
AC supply (non-UPS)
Pin
Description
3L
4N
PE
PE
PE
Connector X2:
230
V
AC supply (UPS)
Pin
Description
1L
2N
PE
PE
PE
Connector X4:
fieldbus
Fieldbus
Pin
Description
CANopen
1
CAN_H
2C
A
N
_
L
3G
N
D
PROFIBUS DP
1
D (N)
2D
(
P
)
DeviceNet 1
CAN_H
2C
A
N
_
L
3G
N
D
Connector X3:
RJ45 cable with
Ethernet
1T
D
+
2T
D
-
3
RD+
4N
C
5N
C
6
RD-
7N
C
8N
C
Casing
PE
2
79
81
