Introduction to the manual 19
Quick installation, commissioning and operation
flowchart
Task See / Action
Plan the installation. Check: ambient conditions,
ratings, required external cooling circuit arrangements,
input power connection, compatibility of the generator,
generator connection, etc.
Select the cables.
Technical data, page 121
Planning the electrical installation, page 53
Option manuals (if optional equipment is included)
Unpack and check the units.
Check the type code indicated on the type designation
label against the original order.
Checking the delivery, page 44
Check that all necessary optional modules and
equipment are present and correct.
If the converter has been non-operational for more than
one year, reform the converter DC link capacitors.
Contact your local ABB representative.
Only intact units may be started up!
Check the installation site. Checking the installation site, page 43
Route the cables. Routing the cables, page 62
Mount the cabinet line-up. Mechanical installation, page 43
Connect the liquid cooling connections. The internal cooling circuit, page 113
Check the insulation of the generator and the rotor
cable.
Checking the insulation of the assembly, page 67
Connect the power cables. Connect the control and the
auxiliary control cables.
Electrical installation, page 67
Check the installation. Installation checklist, page 87
Commission the converter. ACS800-67LC system description and start-up
guide [3AUA0000059432 (English)] and
ACS800-67(LC) doubly-fed induction generator
control program firmware manual
[3AUA0000071689 (English)]
