126 Technical data
Terminal and lead-through data for the control cables
The control cables are internally wired. The counterpart connector data is given in the
table below.
Terminal Identification Type Part number Qty
X1 Han Q 5/0 Crimp terminal Female insert (F) 09 12 005 3101 1
Han 2.5 mm
2
Crimp contact female 09 33 000 6202 5
Han 3A Hood 19 20 003 1440 1
Cable gland M20 1
X2 Han Q 5/0 Crimp terminal Female insert (F) 09 12 005 3101 1
Han 2.5 mm
2
Crimp contact female 09 33 000 6202 5
Han 3A Hood 19 20 003 1440 1
Cable gland M20 1
X3 RJ45 Han3A Complete RJ45 09 45 115 1104 1
X4 Hanbrid Quintax Female insert (F) 09 15 003 3101 1
Hanbrid Quintax Contact female (F) 09 15 004 3113 1
Han 0.5 mm
2
Crimp contact female 09 15 000 6203 4
Han Hanbrid Hood 19 20 003 1440 1
Cable gland M20 1
X5 Han 15D Crimp terminal Female insert (F) 09 21 015 3101 1
Han 1.0 mm
2
Crimp contact female 09 33 000 6205 15
Han 10A Hood 19 20 010 1440 1
Cable gland M20 1
X7 Han 15D Crimp terminal Male insert (M) 09 21 015 3001 1
Han 0.5 mm
2
Crimp contact male 09 15 000 6103 15
Han 10A Hood 19 20 010 1440 1
Cable gland M20 1
X10 Han 10A Crimp terminal Male insert (M) 09 20 010 3001 1
Han 1.0 mm
2
Crimp contact male 09 33 000 6105 8
Han 2.5 mm
2
Crimp contact male 09 33 000 6102 2
Han 10A Hood 19 20 010 1440 1
Cable gland M20 1
X11 Han 15D Crimp terminal Female insert (F) 09 21 015 3101 1
Han 1.0 mm
2
Crimp contact female 09 33 000 6205 11
Han 10A Hood 19 20 010 1440 1
Cable gland M20 1
X8.2 Han Hv E Screw terminal Female insert (F) 09 34 006 2701 1
Han 16B Hood 19 34 006 0421 1
Cable gland M25 1
X8.1 Han Hv E Screw terminal Female insert (F) 09 34 006 2701 1
Han 16B Hood 19 34 006 0421 1
Cable gland M25 1
X9 Han 4A Screw terminal Female insert (F) 09 20 004 2711 1
Han 3A Hood 19 20 003 1440 1
Cable gland M20 1
X6.2 Han 16A Crimp terminal Male insert (M) 09 20 016 3001 1
Han 1.0 mm
2
Crimp contact male 09 33 000 6105 16
Han 16A Hood 19 20 016 1440 1
Cable gland M20 1
