Technical data 129
Materials
Auxiliary circuit current consumption
Cooling fans
UPS supply
Voltage 230 V AC ± 5%, frequency 50 Hz or 60 Hz, typical power consumption < 500 W,
maximum power and current consumption 5000 W / RMS 20 ms and 25 A / RMS 20 ms at
start-up.
Non-UPS supply
Voltage 230 V AC ± 5%, frequency 50 Hz or 60 Hz, typical continuous power consumption
< 2000 W, maximum peak power and current consumption < 4000 W / RMS 20 ms,
maximum I
peak
= 20 A. Note: These are maximum values when optional power cabinet is
selected (option +C108 or +C109).
Vibration (IEC 60068-2) 0.075 mm (0…58 Hz)
10 m/s
2
(58…150 Hz)
Marine requirements:
±1 mm (0.04 in.) (peak
value, 2…13.2 Hz)
0.7g (13.2…100 Hz)
Max. amplification 10
1.5 mm (2…9 Hz)
5 m/s
2
(9…200 Hz)
(1M2, IEC 60721-3-1)
3.5 mm (0.14 in.)
(2…9 Hz)
10 m/s
2
(9…200 Hz)
Random 10…200 Hz
Acceleration spectral
density 1 m
2
/s
3
(2M2, IEC 60721-3-2)
Shock (IEC 60068-2-29) Not allowed Max. 100 m/s
2
(330 ft/s
2
),
11 ms
Max. 100 m/s
2
(330 ft/s
2
),
11 ms
Free fall Not allowed 100 mm (4 in.) 100 mm (4 in.)
Cabinet Hot-dip zinc-coated (thickness approx. 20 µm) steel sheet (thickness 1.5 mm) with
polyester thermosetting powder coating (thickness approx. 80 µm) on visible surfaces
except back panel. Colour: RAL 7035 (light beige, semigloss).
Busbars Tin- or silver-plated copper
Internal cooling circuit
piping
Aluminium, acid-fast stainless steel, PA pipes
Fire safety of materials
(IEC 60332-1)
Insulating materials and non-metallic items: Mostly self-extinctive
Packaging Frame: Wood or plywood. Plastic wrapping: PE-LD. Bands: PP or steel.
Disposal The converter contains raw materials that should be recycled to preserve energy and
natural resources. The package materials are environmentally compatible and
recyclable. All metal parts can be recycled. The plastic parts can either be recycled or
burned under controlled circumstances, according to local regulations. Most
recyclable parts are marked with recycling marks.
If recycling is not feasible, all parts excluding electrolytic capacitors and printed circuit
boards can be landfilled. The DC capacitors (C1-1 to C1-x) contain electrolyte and the
printed circuit boards contain lead, both of which are classified as hazardous waste
within the EU. They must be removed and handled according to local regulations.
For further information on environmental aspects and more detailed recycling
instructions, please contact your local ABB distributor.
Unit Type
ISU and INU D2E146-AP47-xx
ACU and ICU400 W2E 143-AA09-01
