Technical data 125
 Internal cooling circuit data
See chapter The internal cooling circuit.
LCL filter data
Terminal and lead-through data for the power cables
For description of lead-through types, see chapter Operation principle and hardware
description, page 32.
ACS800-67LC-
Liquid massflow l/min (m
3
/h)
ICU200
With option
+C111
With option
+C108 or
+C109
With option
+D150
With options
+D150 and +C111
With options
+D150 and
+C108 or +C109
1075/0575-7 75 (4.5) 85 (5.1) 100 (6.0) 93 (5.6) 103 (6.2) 118 (7.1)
1375/0575-7 75 (4.5) 85 (5.1) 100 (6.0) 93 (5.6) 103 (6.2) 118 (7.1)
1375/1125-7 100 (6.0) 110 (6.6) 125 (7.5) 118 (7.1) 128 (7.7) 143 (8.6)
1595/0865-7 115 (6.9) 125 (7.5) 140 (8.4) 142 (8.5) 152 (9.1) 167 (10.0)
2035/1125-7 115 (6.9) 125 (7.5) 140 (8.4) 142 (8.5) 152 (9.1) 167 (10.0)
ACS800-67LC-
Liquid quantity l
ICU200
With option
+C111
With option
+C108 or
+C109
With option
+D150
With options
+D150 and
+C111
With options
+D150 and
+C108 or +C109
1075/0575-7 11 12 13 11 12 13
1375/0575-7 11 12 13 11 12 13
1375/1125-7 14 15 16 14 15 16
1595/0865-7 16 17 19 16 18 19
2035/1125-7 16 17 19 16 18 19
ACS800-67LC-
LCL filter L1 L2 C
Type code
MRP
code
Inductance
uH
MRP
code
Inductance
uH
MRP
code
Capacitance
uF
MRP
code
1075/0575-7 ALCL-15LC-7 68462193 106 68459559 190 68459656 64 68459737
1375/0575-7 ALCL-15LC-7 68462193 106 68459559 190 68459656 64 68459737
1375/1125-7 ALCL-25LC-7 68462258 54 68459681 97 68459699 125 68459753
1595/0865-7 ALCL-24LC-7 68462215 70 68459664 127 68459672 96 68459745
2035/1125-7 ALCL-25LC-7 68462258 54 68459681 97 68459699 125 68459753
Cable terminals Screw size Tightening torque
DC terminals M12
Max. intrusion into module: 20 mm (0.8 in.)
50 N·m (37 lbf·ft)
Input busbars
(L1, L2, L3)
M12 70 N·m (52 lbf·ft)
Output busbars
(U2, V2, W2)
M12 70 N·m (52 lbf·ft)
PE terminals M12 70 N·m (52 lbf·ft)
