Rockwell Automation Publication 825-UM004D-EN-P - November 2012 119
825-PDN DeviceNet Communication Card Chapter 9
2. Set the data rate switches.
Table 54 - Data Rate Setting
3. Cycle power to the card to initialize the new settings.
Using RSNetWorx for DeviceNet
Follow these steps if the hardware switches are left in the factory default settings
or in the range of 64…99 for the node address and 3…9 for the data rate. To begin
the configuration of the 825-P Modular Protection System using software,
execute the RSNetWorx software and complete the following procedure. You
must use RSNetWorx Revision 3.21 Service Pack 2 or later.
1. After going on-line using RSNetWorx for DeviceNet, do the following:
• Select the Net
work menu.
• Select Online.
2. Ch
oose the appropriate DeviceNet PC interface. In this example, a
1784-P
CIDS module is chosen. Other common DeviceNet interfaces
are the 1770-KFD, and 1784-PCD.
3. Select OK.
4. RSNetWorx notifies the user to upload or download devices before
vi
ewing configuration. Select OK.
5. R
SNetWorx now browses the network and displays all of the nodes it has
det
ected on the network. For some versions of RSNetWorx software, the
825-P Modular Protection System EDS files and icon might not be
included, and the device could be identified as an unregistered device.
If the screen appears like in Figure 42, continue with Registering
an EDS file.
Switch Setting Description
0125 K
1250 K
2500 K
3…9 For a switch setting in this range, data rate setting is determined by the
software setting using the RSNetWorx for DeviceNet configuration tool.
Note: The card is factory default set to autobaud to the network data rate.
9 Factory default setting.
NOTE: DeviceNet drivers must be configured using RSLinx prior to being available to RSNetWorx.
