DeviceNet Information Chapter E
• Instance 4 = Misc.
• Instance 5 = DeviceLogix Parameters
• Instance 6-n = Motor Relay specific parameter groups
Th
e following instance attributes are supported for all parameter group instances:
The foll
owing common services are implemented for the Parameter Group
Object:
Discrete Output Group
Object - CLASS CODE
0x001E
No class attributes are supported for the Discrete Output Group Object.
Supported instances of the Discrete Output Group Object are listed below.
Instance 1 contains the following attributes:
Instance 2 contains the following attributes:
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING
2 Get Number of Members UINT
3Get1
st
Parameter UINT
4Get2
nd
Parameter UINT
nGetN
th
Parameter UINT
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
Attribute ID Access Rule Name Data Type Value
3 Get Number of
Instances
USINT 10
4 Get Binding Array of UINT List of DOP instances
6 Get/Set Command BOOL 0 = idle and 1 = run
104 Get/Set Network Status
Override
BOOL 0 = No Override (go to safe state)
1 = Override (run local logic)
105 Get/Set Comm Status
Override
BOOL 0 = No Override (go to safe state)
1 = Override (run local logic)
