Allen-Bradley 825-P User Manual

Rockwell Automation Publication 825-UM004D-EN-P - April 2012 261
DeviceNet Information Chapter E
Control Supervisor Object -
CLASS CODE 0x0029
No class attributes are supported.
Only Instance 1 of the Control Supervisor Object is supported. The following
instance attributes are supported:
The following common services are implemented for the Control Supervisor
Object:
Acknowledge Handler
Object - CLASS CODE
0x002b
No class attributes are supported for the Acknowledge Handler Object.
Only Instance 1 of the Acknowledge Handler Object is supported. The
following instance attributes are supported:
The following common services are implemented for the Acknowledge Handler
Object:
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
10 Get Tripped BOOL
11 Get Warning BOOL
12 Get/Set Fault Reset BOOL 0->1 = Trip Reset
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get/Set Acknowledge Timer UINT milliseconds
2 Get Retry Limit USINT 1
3 Get COS Producing Connection Instance UINT 4
