Chapter E DeviceNet Information
Custom Parameter Based
Input (Produced) Assembly
Instance 100
1
187 Produced Warn Status 1
188 Produced Warn Status 2
189 Produced Module Status Bits
Instance Type Description
Instance 100
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 Value of the parameter pointed to by “Produced Word 0 Param” (low byte)
1 Value of the parameter pointed to by “Produced Word 0 Param” (high byte)
1 2 Value of the parameter pointed to by “Produced Word 1 Param” (low byte)
3 Value of the parameter pointed to by “Produced Word 1 Param” (high byte)
2 4 Value of the parameter pointed to by “Produced Word 2 Param” (low byte)
5 Value of the parameter pointed to by “Produced Word 2 Param” (high byte)
3 6 Value of the parameter pointed to by “Produced Word 3 Param” (low byte)
7 Value of the parameter pointed to by “Produced Word 3 Param” (high byte)
4 8 Value of the parameter pointed to by “Produced Word 4 Param” (low byte)
9 Value of the parameter pointed to by “Produced Word 4 Param” (high byte)
5 10 Value of the parameter pointed to by “Produced Word 5 Param” (low byte)
11 Value of the parameter pointed to by “Produced Word 5 Param” (high byte)
6 12 Value of the parameter pointed to by “Produced Word 6 Param” (low byte)
13 Value of the parameter pointed to by “Produced Word 6 Param” (high byte)
7 14 Value of the parameter pointed to by “Produced Word 7 Param” (low byte)
15 Value of the parameter pointed to by “Produced Word 7 Param” (high byte)
