58 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 5 Using MPS Explorer
TAR (Display Target Words)
The Display Target Words function shows the status of relay elements and is
independent from the main window. To view the full bit description, place the
cursor over any masked heading.
Dialog buttons function as follows:
Start: Begin data collection based on the contents of the Times and Interval boxes
Stop: Sto
p collecting data at any time
Show all: Display ever
y row sequentially one time
Clear: Clear th
e list contents on the screen
Exit: Hide th
e data acquisition screen. If data is being acquired via the Start button, it will stop
automatically when the window is hidden.
Export CSV: Export the da
ta in the list to a Comma Separated Value file (.csv) for external analysis. If
rows are selected a prompt will be displayed asking to sav
e all rows or just the selection.
Times Interval Action
Empty Empty Poll Row # as fast as possible until Stop button is clicked
Empty Number Poll Row #at every time interval until Stop button is clicked
Number Empty Poll Row # as fast as possible until Times numb
er of sets have
been acquired
Number Number Poll Row # at every time interval until Times number of sets
have been acquired
NOTE: To conserve program memory, only the last 500 rows will be displayed on the screen
at a time. All data will be placed into a temporary file.
